Merk: Mondraker
Type: e-MTB, e-Trail
Kleur: Vortex Grey
Afmontage: Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Frame materiaal: Carbon
Conditie: Nieuw
Frame Prime 6061 Xtralite Full Butted Alloy, Forward Geometry, internal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
Sizes XS: 380mm / S: 390mm / M: 430mm / L: 470mm / XL: 510mm
Fork RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem MDK Urban 35mm, 6061 forged alloy, 31.8mm barbore
Stuur MDK Urban 1.0 double butted 6061 alloy, rise: 20mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips Onoff Shaper
Seatpost Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
Zadel MDK urban
Front brake Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
Rear brake Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
Rims MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes
Spaken CN round stainless steel
Front hub Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts Rear hub Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts, HG freehub
Voorband Maxxis Grifter 29×2.5, single compound, 60TPI, wire bead, tanned wall. Achterband Maxxis Grifter 29×2.5, single compound, 60TPI, wire bead, tanned wall.
Crankset Race Face Aeffect ebike, 165mm Rings Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Pedalen Urban pedal resin black
Chain Sram SX Eagle, 12s, Powerlock
Rear derrailleur Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
Shift levers Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click
Casette Sram PG-1210, 11-50T, 12s
Derailleur hanger Mondraker M068
Others Front light: 50LUX output DC 6-12V, waterproof Alloy cage. Rear Light: Fender Mount, w/ Reflective, e-bike version, 6-12V. Fenders: Alloy black MDK custom fenders. Rack: Alloy MDK rear Rack, Max loading 25kg. Kickstand: Massload KSA18-40
Gewicht 24,5 kg
Display Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller
Motor Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM
Battery Bosch Powertube 625Wh
